Lithium ion Polymer Cells for Small Size Series

Update: 2016/2/17      View:
  • Brand:    Starnovo
  • Type:
  • Price:     RMB
  • Promotion:     RMB ( 0 Customers Bought)
  • Order Online   Add to favorites
Introduction


Main Features & Applications

 Super thin design: the thickness can be 3-6mm,narrowest width can be  12mm or so;

 High discharge plateau: medium voltage is above 3.7V;

 High output power: single cell of 2C discharge capacity is 90% of 0.5C discharge capacity;

 Long cycle life: >500 cycles;

 Available for wireless products, bluetooth products,  MP3/MP4, electronic mater, digital products.

 Products Specifications

Model

Nominal

 Voltage

(V)
Nominal
Capacity
(mAh)

Internal

 Resistance

(mΩ)
Dimension (mm) Weight
(g)
Thickness Width Length
SNO-203040P 3.7 210 100 2.5 30 40 5.0
SNO-252148P 3.7 200 110 2.5 21 48 5.0
SNO-281222P 3.7 45 450 2.8 12 22 1.2
SNO-301320P 3.7 50 450 3.0 13 20 1.5
SNO-301525P 3.7 70 320 3.0 15 25 1.8
SNO-301528P 3.7 75 300 3.0 15 28 1.8
SNO-301530P 3.7 80 220 3.0 15 30 2.0
SNO-301846P 3.7 180 160 3.0 18 46 4.0
SNO-302025P 3.7 110 200 3.0 20 25 2.7
SNO-302222P 3.7 100 250 3.0 22 22 2.7
SNO-302323P 3.7 110 200 3.0 23 23 3
SNO-303035P 3.7 280 110 3.0 30 35 6
SNO-303040P 3.7 310 70 3.0 30 40 7
SNO-303450P 3.7 400 60 3.0 34 50 10
SNO-321538P 3.7 130 180 3.2 15 38 3.3
SNO-331030P 3.7 70 300 3.3 10 30 1.8
SNO-332832P 3.7 250 100 3.3 28 32 5.6
SNO-341028P 3.7 60 315 3.4 10 28 1.8
SNO-351013P 3.7 15 1300 3.5 10 13 1.0
SNO-351018P 3.7 30 450 3.5 10 18 1.0
SNO-351126P 3.7 55 380 3.5 11 26 1.8
SNO-351420P 3.7 70 300 3.5 14 20 1.8
SNO-351445P 3.7 180 180 3.5 14 45 4.0
SNO-352025P 3.7 110 280 3.5 20 25 2.8
SNO-363135P 3.7 380 100 3.6 31 35 8.0
SNO-361219P 3.7 45 330 3.6 19 19 1.6
SNO-362828P 3.7 240 100 3.6 28 28 5.5
SNO-371025P 3.7 50 380 3.7 10 25 1.8
SNO-381120P 3.7 45 380 3.8 11 20 1.5
SNO-401022P 3.7 50 380 4.0 10 22 1.8
SNO-401118P 3.7 40 380 4.0 11 18 1.5
SNO-401120P 3.7 55 300 4.0 11 20 1.8
SNO-401230P 3.7 105 180 4.0 12 30 2.8
SNO-401323P 3.7 80 280 4.0 13 23 2.0
SNO-401730P 3.7 150 160 4.0 17 30 4.0
SNO-401818P 3.7 60 280 4.0 18 18 1.8
SNO-401822P 3.7 90 250 4.0 18 22 2.7
SNO-402025P 3.7 150 220 4.0 20 25 4.0
SNO-402028P 3.7 170 200 4.0 20 28 5.0
SNO-402030P 3.7 200 180 4.0 20 30 5.5
SNO-402046P 3.7 340 100 4.0 20 46 8.0
SNO-402050P 3.7 360 100 4.0 20 50 8.2
SNO-402332P 3.7 240 120 4.0 23 32 5.8
SNO-402827P 3.7 250 100 4.0 28 27 5.8
SNO-421133P 3.7 110 260 4.2 11 33 3.0
SNO-431230P 3.7 125 220 4.3 12 30 3.2
SNO-432030P 3.7 220 110 4.3 20 30 6
SNO-442027P 3.7 190 120 4.4 20 27 5.5
SNO-442040P 3.7 300 100 4.4 20 20 6.5
SNO-451220P 3.7 70 300 4.5 12 20 2.0
SNO-451725P 3.7 120 250 4.5 17 25 3.2
SNO-451828P 3.7 220 110 4.5 18 28 6.0
SNO-451225P 3.7 100 260 4.5 12 25 2.8
SNO-452030P 3.7 220 110 4.5 20 30 6.0
SNO-452248P 3.7 430 60 4.5 22 48 9.2
SNO-452323P 3.7 210 120 4.5 23 23 6.0
SNO-452626P 3.7 230 100 4.5 26 26 6.2
SNO-453030P 3.7 360 80 4.5 30 30 8.0
SNO-453040P 3.7 500 60 4.5 30 40 12.5
SNO-453640P 3.7 680 60 4.5 36 46 13.5
SNO-471736P 3.7 260 80 4.7 17 36 6.5
SNO-481220P 3.7 80 280 4.8 12 20 2.6
SNO-482834P 3.7 450 60 4.8 28 34 11.5
SNO-483245P 3.7 700 60 4.8 32 45 14.0
SNO-501120P 3.7 75 280 5.0 11 20 2.6
SNO-501215P 3.7 45 320 5.0 12 15 1.8
SNO-501218P 3.7 60 300 5.0 12 18 2.0
SNO-501220P 3.7 80 280 5.0 12 20 2.6
SNO-501230P 3.7 120 250 5.0 12 30 3.0
SNO-501240P 3.7 200 120 5.0 12 40 6.0
SNO-501417P 3.7 70 280 5.0 14 17 2.6
SNO-501430P 3.7 160 220 5.0 14 30 5.0
SNO-501525P 3.7 140 240 5.0 15 25 3.2
SNO-501530P 3.7 180 200 5.0 15 30 4.3
SNO-501537P 3.7 230 120 5.0 15 37 6.5
SNO-501634P 3.7 250 100 5.0 16 34 6.8
SNO-501646P 3.7 360 80 5.0 16 46 7.3
SNO-502025P 3.7 200 120 5.0 20 25 6.0
SNO-502030P 3.7 260 80 5.0 20 30 7.0
SNO-502035P 3.7 300 60 5.0 20 35 7.5
SNO-502040P 3.7 380 60 5.0 20 40 8.5
SNO-502060P 3.7 600 60 5.0 20 60 12.0
SNO-502236P 3.7 370 60 5.0 22 36 7.3
SNO-502248P 3.7 500 60 5.0 22 48 10.0
SNO-502530P 3.7 320 60 5.0 25 30 8.0
SNO-502540P 3.7 500 60 5.0 25 40 10.0
SNO-502833P 3.7 380 60 5.0 28 33 8.5
SNO-503030P 3.7 450 60 5.0 30 30 9.0
SNO-503035P 3.7 500 60 5.0 30 35 10.0
SNO-503040P 3.7 560 60 5.0 30 40 11.2
SNO-503048P 3.7 750 60 5.0 30 48 15.5
SNO-503443P 3.7 500 60 5.0 34 43 10.0
SNO-503450P 3.7 900 60 5.0 34 50 17.5
SNO-503535P 3.7 600 60 5.0 35 25 12.0
SNO-521538P 3.7 240 110 5.2 15 38 5.4
SNO-521657P 3.7 400 70 5.2 16 57 8.8
SNO-522030P 3.7 300 100 5.2 20 30 7.5
SNO-522037P 3.7 380 80 5.2 20 37 8.5
SNO-531118P 3.7 55 350 5.3 11 18 2.0
SNO-531230P 3.7 140 280 5.3 12 30 4.0
SNO-531444P 3.7 260 100 5.3 14 44 5.8
SNO-551323P 3.7 120 300 5.5 13 23 4.0
SNO-551333P 3.7 180 200 5.5 13 33 4.3
SNO-551417P 3.7 55 300 5.5 14 17 2.3
SNO-551430P 3.7 180 200 5.5 14 30 4.3
SNO-551818P 3.7 100 320 5.2 18 18 2.6
SNO-552035P 3.7 340 80 5.5 20 35 8.0
SNO-552027P 3.7 250 100 5.5 20 27 5.7
SNO-552552P 3.7 700 60 5.5 25 52 14.0
SNO-553450P 3.7 1000 60 5.5 34 50 15.0
SNO-581663P 3.7 530 60 5.8 16 63 12.5
SNO-601220P 3.7 95 300 6.0 12 20 2.6
SNO-601230P 3.7 150 220 6.0 12 30 4.0
SNO-601235P 3.7 200 200 6.0 12 35 4.5
SNO-601337P 3.7 180 200 6.0 13 37 4.3
SNO-601417P 3.7 70 320 6.0 14 17 3.6
SNO-601636P 3.7 280 100 6.0 16 36 5.8
SNO-601663P 3.7 560 60 6.0 16 63 13.0
SNO-602020P 3.7 170 200 6.0 20 20 3.2
SNO-602025P 3.7 190 200 6.0 20 25 4.5
SNO-602030P 3.7 300 80 6.0 20 30 6.0
SNO-602040P 3.7 420 60 6.0 20 40 9
SNO-602533P 3.7 450 60 6.0 25 33 9.5
SNO-602535P 3.7 500 60 6.0 25 35 10.0
SNO-602540P 3.7 580 60 6.0 25 40 11.5
SNO-602730P 3.7 400 80 6.0 30 30 8.8
SNO-631636P 3.7 300 100 6.3 16 36 6.0
SNO-651730P 3.7 250 180 6.5 17 30 5.5
SNO-652023P 3.7 200 200 6.5 20 23 4.8
SNO-652025P 3.7 230 200 6.5 20 25 5.0
SNO-652525P 3.7 340 80 6.5 25 25 7.0
SNO-651730P 3.7 280 110 6.5 17 30 6
SNO-671323P 3.7 150 200 6.7 13 23 3.0
SNO-701245P 3.7 300 100 7.0 12 45 6.5
SNO-701440P 3.7 320 80 7.0 14 40 6.3
SNO-701528P 3.7 200 200 7.0 15 28 4.8
SNO-701834P 3.7 380 80 7.0 18 34 7.0
SNO-702060P 3.7 800 60 7.0 20 60 16.0
SNO-703040P 3.7 800 60 7.0 30 40 16.0
SNO-752443P 3.7 600 60 7.5 24 43 12.0
SNO-801530P 3.7 270 100 8.0 15 30 6.2
SNO-802025P 3.7 300 100 8.0 20 25 6.4
SNO-802444P 3.7 800 60 8.0 24 44 16.0
SNO-832230P 3.7 480 60 8.3 22 30 9.5
SNO-852528P 3.7 500 60 8.5 25 28 10.0
